Building cool stuff since 1996

3D Printing

Custom designed and printed pliers for component assembly.

Fabrication

Assembly fixture for rescue board.

Design

Rescue board designed for a tactical team to use in extracting a victim.  Designed in Solidworks, CNC machined, and assembled.

Automation

Automatic gate-removing system for die-cast parts.

Automation

Automated multi-point inspection system for surgical tool.  Inspections included force measurement, angular adjustment, and exercising of unit-under-test.

Design &Fabrication

Sampling Head for Mobile Mining Sampler.  All components were designed, fabricated, and assembled in-house.

Fabrication

Custom motor and transmission mounts made for a vehicle engine  swap.  Parts were cut on CNC plasma machine, TIG welded, and plated in yellow zinc chromate.

Composites

Carbon-fiber robot tooling makes for a stronger, lighter, faster robotic cell.

Design

Mass-flow calibration machine designed to flexibly run multiple different coreolis meters thru different test protocols.

Machining

Designed and machined in-house, this oil filter relocation plate replaces the factory oil filter housing on a Ford 2.0 EcoBoost engine.

Design

We designed, assembled, and installed Mass-Flow calibration machine in Chihuahua, Mexico for Micro Motion.  It is now the most accurate calibration stand in the world.

Automation

Automatic insert press for ceramic insulation tile.  Just runs and runs and runs...

Automation

Robotic pick and place system for small ceramic cylinders.  Multiple input and output trays ensure this system never sits idle.

Design &Fabrication

Here's the Mobile Mining Sampler in action.  This design drastically improved the quality of cuttings samples being taken, and was more ergonomic for operators than the manual sampling method.

Fabrication

Full aluminum intercooler charge pipe.  Features a machined sensor mount, bead-rolled ends, and fully tig-welded joints.  Pressure tested to 30 psi.

Composites

More Carbon-fiber robot tooling. This unit was very cool - it replaced a heavy single-part tool with this light, stiff dual-point assembly.
